EIGHT-CHANNEL MIC PRE WITH A-D/D-A CONVERSION AND ANALOGUE COMPRESSION
- Eight natural-sounding Scarlett mic preamps
- Flexible analogue compression on every channel
- Eight balanced line inputs
- Focusrite precision A-D/-DA conversion up to sample rates of 192kHz
EIGHT SCARLETT MIC PRES
Building on the features of the Scarlett OctoPre, Scarlett OctoPre Dynamic brings you the ultimate Scarlett expansion with eight Scarlett mic preamps and analogue compression on every input channel providing a musical, soft-knee style of compression for more subtle control of your dynamics. The MORE button then allows you to double the ratio for more aggressive compression effects.
DUAL HIGH-HEADROOM INSTRUMENT INPUTS
Two high-headroom instrument inputs will handle high-output guitar pickups. Don’t forget to engage a bit of compression, great for controlling the dynamics of electric basses and guitars.
EXPAND THE NUMBER OF OUTPUTS IN YOUR STUDIO
Scarlett OctoPre Dynamic’s eight analogue outputs can be sourced either directly from the mic preamps for live use, or via the ADAT inputs to give you eight more analogue outputs channels from your DAW.
SPECIFICATIONS IN DETAIL
We always quote ‘real world’ performance figures (measured to the AES17 standard). Some companies choose to quote chipset performance, which is misleading, and here’s why.
SUPPORTED SAMPLE RATES
44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
MICROPHONE INPUTS
- Frequency Response
- 20Hz – 20kHz +0.5/-1.5dB
- Dynamic Range
- 109 dB (A-Weighted)
- THD+N
- <0.001%
- Noise EIN
- -127 dBu
- Maximum input level (without pad)
- +8 dBu
- Maximum input level (with pad)
- +16 dBu
- Gain Range
- 50 dB
- Input Impedance
- 3 kΩ
LINE INPUTS
- Frequency Response
- 20Hz – 20kHz +0.5/-1.5dB
- Dynamic Range
- 109 dB (A-Weighted)
- THD+N
- <0.002%
- Maximum input level
- +22 dBu
- Gain Range
- 50 dB
- Input Impedance
- 49 kΩ
INSTRUMENT INPUTS
- Frequency Response
- 20Hz – 20kHz +0.5/-1.5dB
- Dynamic Range
- 108 dB (A-Weighted)
- THD+N
- <0.01%
- Maximum input level
- +13 dBu
- Gain Range
- 50 dB3
- Input Impedance
- 1 MΩ
LINE OUTPUTS
- Maximum Output Level (0 dBFS)
- +16dBu @ 0dBFS, or >21dBu where ADAT output is not used
- THD+N
- <0.001%
- Ouput Impedance
- 136 Ω (Balanced)
